您现在的位置>>公司首页>>产品总览>> 扬 声 器
::扬 声 器::
外观图 Appearance 技术特性 Specifications Enter
DIMENSIONAL ∮15.0×3.0mm
NOMINAL POWER 1mw
IMPEDANCE  150ohm±15% at 1KHz
SOUND PRESSURE LEVEL
1mw on IECR 318
Standard 98±3dB
RESONANCE FREQUENCY 200-6KHz
DIMENSIONAL ∮15.0×2.8mm
NOMINAL POWER 1mw
IMPEDANCE  150ohm±15% at 1KHz
SOUND PRESSURE LEVEL
1mw on IECR 318
Standard 96±3dB
RESONANCE FREQUENCY 200-5KHz
DIMENSIONAL ∮13.0×2.5mm
NOMINAL POWER 1mw
IMPEDANCE  32ohm±15% at 1KHz
SOUND PRESSURE LEVEL
1mw on IECR 318
Standard 114±3dB
RESONANCE FREQUENCY 200-3KHz
DIMENSIONAL ∮13.0×2.8mm
NOMINAL POWER 1mw
IMPEDANCE  32ohm±15% at 1KHz
SOUND PRESSURE LEVEL
1mw on IECR 318
Standard 110±3dB
RESONANCE FREQUENCY 200-4KHz
DIMENSIONAL ∮13.0×5.4mm
NOMINAL POWER 1mw
IMPEDANCE  150ohm±15% at 1KHz
SOUND PRESSURE LEVEL
1mw on IECR 318
Standard 110±3dB
RESONANCE FREQUENCY 200-4KHz
DIMENSIONAL ∮20.0×4.6mm
NOMINAL POWER 0.2w
IMPEDANCE  8ohm±15% at 1KHz
SOUND PRESSURE LEVEL
86±3dB
RESONANCE FREQUENCY 600±20%Hz
DIMENSIONAL ∮23.0×8.5mm
NOMINAL POWER 0.15w
IMPEDANCE  8ohm±15% at 1KHz
SOUND PRESSURE LEVEL
80±3dB
RESONANCE FREQUENCY 1100±20%Hz
DIMENSIONAL ∮32×15mm
NOMINAL POWER 0.15w
IMPEDANCE  100ohm±15% at 1KHz
SOUND PRESSURE LEVEL
88±3dB
RESONANCE FREQUENCY 1100±20%Hz

蜂 鸣 器 传 声 器

　
